Lean, Mean Working Machines. With a powerful Yanmar diesel engine, the new 3640E model is a "little giant" that maneuvers easily in tight places and handles tough construction, agriculture and landscaping challenges with ease.
GEHL 3640E
Specs At A Glance
  • Model 3640E
  • Rated Operating Load (kg): 1050 lbs. (476)
  • Rated Operating Load w/ Optional Counterweight (kg): 1175 lbs. (533)
  • Engine Model: Yanmar 3TNV88
  • Net Power (kW) @RPM: 35hp (26) @2600
  • Detailed Spec Sheet


  • View Larger Image



  • Compact, low-profile design - for maneuverability in narrow, low-clearance areas
  • Powerful Yanmar diesel engines - for power and performance where it counts
  • All-Tach® attachment mounting system - compatible with most attachments.

Additional Features
Dual-hand and joystick controls not available on models 3640E and 4240E
Hand/Foot Controls
 Dual-hand and joystick controls not available on models 3640E and 4240E
T-Bar "Hands Only" Controls
 Optional counterweight increases rated operating load from 1050 lbs. (476 kg) to 1175 lbs. (533 kg)
Optional Counterweight
All-Tach™ Attachment System

Standard Equipment
Optional Equipment

  • Adjustable Seat
  • Adjustable Seatbelt
  • All-Tach™ Attachment System
  • Battery Charge Indicator Lamp
  • Controls: T-bar "Hands-only, Hand-Foot
  • Coolant Temperature Gauge
  • Dual-Element Air Cleaner with Visual Indicator
  • Dual Front and Rear Work Lights
  • Engine Intake Air Pre-Heater Starting Assist (Manual)
  • Foot (T-Bar controls only) and Hand Throttle
  • Front Auxiliary Hydraulics with ¾-inch Flat-faced couplers
  • Fuel Gauge
  • Headliner and Accoustical Interior
  • Hourmeter
  • Hydraloc System – Brakes and Interlock for Starter, Lift/Tilt Cylinders, Auxiliary Hydraulics and Wheel Drives
  • Independent Hydraulic Reservoir and Hydraulic Oil Cooler
  • Lift Arm Support Device
  • Low Oil Pressure Light and Buzzer
  • Manual Control Hydrostatic Drive
  • Number 80K Chain Drive
  • Operator Restraint Bar with Armrests
  • Power Plug (12V)
  • Powerview® Lift Arm
  • Removeable Belly Plate and Access Cover
  • ROPS/FOPS Level II
  • Seatbelt Indicator Lamp and Buzzer
  • Spark Arrestor Muffler
  • Top and Rear Windows
  • Vandalism Lock Provisions
  • Visual Hydraulic Filter Indicator
  • Warning Lamps and Buzzer – Engine and Hydraulic Oil Temperature

  • 3-inch Wide Seatbelt – When Required
  • Audible Back-up Alarm
  • Battery Disconnect Switch
  • Bucket Bolt-on Cutting Edge
  • Cab Door with Wiper and Dome Light
  • Centrifugal Pre-Cleaner
  • Deluxe Sound Package
  • Diesel Engine Exhaust Purifier
  • Engine Auto-Shutdown System
  • Engine Block Heater
  • Fenders
  • Four-Point Lift Kit
  • Heater/Defroster
  • Horn
  • Hydraulic Coupler Kit
  • Impact-Resistant Door
  • Interior Dome Light
  • Rear Counterweight
  • Rear View Mirror
  • Single-Point Lift Kit
  • Self-Leveling Lift Action
  • Sliding Side Windows
  • Strobe Light
  • Suspension Seat





* (air-conditioning not available on 3640E/4240E)
